Provides DC 12V to AC 120V Continuous Power
Technical Specifications
Output Continuous Watts(W)
1100W+18W USB
Surge Capacity (PeakPower)
2200W
Rated Input DC (V,A)
12V Battery, 100A
Input Voltage Range
10.5-16Vdc±0.3V
Rated Frequency (Hz)
60Hz±1
Rated Output AC (V,A)
115Vac±10%, 9.5A
Rated Output USB (V,A)
2*QC3.0 USB Ports (5V/3A,9V/2A,18W max)
No Load Current
<1A
Optimum Efficiency
85% min
Fuse (A)
30A*4
FuseType
Internal Blade
Output Wave Form
Pure Sine Wave
Touch Temperature
65℃(149℉)max
Operating Temperature
-20℃~40℃ (4℉~104℉)
Operating/Storage Humidity RH
5~95%
Cooling System
Thermo Fan
Dimensions (L*W*H)
10.6*9.8*4.1 in
Assembled Weight (kg)
3.65kg
External Fuse (Max Load Current)
120A
