If efficiency, reliability and affordable are high on your wish list, ECO-WORTHY 100W 200W 12V expandable Solar Kit is an ideal choice. This system could generate approximately 0.4kWh 0.8kWh per day.
ECO-WORTHY 100 Watt 12V Mono solar panel is fully weather proof and professionally made with high quality components. 25-year linear power guarantee.
ECO-WORTHY LiFePO4 Lithium Iron Phosphate Battery has twice the power, half the weight and lasts 8 times longer than a sealed lead acid battery.
600W Pure Sine Wave Inverter provides high-quality AC power equivalent to grid power to protect your household appliances and electronic equipment, especially suitable for sensitive electrical appliances.
ECO-WORTHY 100W 200W 12V Solar Kit can be used for several different purposes, including cottages, weekends, cabins, boats, RVs, Campers, etc. Whatever the kit is used for, you can rest assured that you are purchasing a quality system. Run a small stereo, laptop computer, cell phone charger, lights or TV. These size systems need conscious conservation of energy. If you have any questions regarding this product, please contact us info@eco-worthy.com.
Package Includes
100W (1-Panel) 12V Solar Kit
1x 100W Mono Solar Panel
1x 30A PWM Solar Controller
1x 5M 12AWG Extension Cable with MC4
1x Z Mounting Bracket
Inverter & Battery Options-
Complete Kit (optional)
with
1x 1.5M Tray Cable
1x 600W 12V-110V Pure Sine Wave Inverter
1x 50Ah 12V LiFePO4 Lithium Battery
200W (2-Panel) 12V Solar Kit
2x 100W Mono Solar Panel
1x 30A PWM Solar Controller
1x 5M 12AWG Extension Cable with MC4
2x Z Mounting Bracket
1x Y MC4 Connector
Inverter & Battery Options-
Complete Kit (optional)
with
1x 1.5M Tray Cable
1x 600W 12V-110V Pure Sine Wave Inverter
1x 50Ah 12V LiFePO4 Lithium Battery
100W Monocrystalline Solar Panel
| Rated Power: 100W |
Solar Cell: Monocrystalline |
| Maximum/Peak Voltage(Vmp): 20.2V |
Open Circuit Voltage(Voc): 24.5V |
| Short circuit current: 5.20A |
Maximum current: 4.95A |
| Output Tolerance: ±3% |
Temperate coefficient of Isc: (010+/-0.01)%/℃ |
| Temperate coefficient of Voc: -(0.38+/-0.01)%/℃ |
Temperature range:－40℃～ +85℃ |
| Frame: Aluminum alloy frame |
Length of extension cable: 90cm（2.95ft） |
| Size of extension cable: 4mm²（11AWG）/MC4 Connector |
Weight: 11.46 lbs(5.20 kg) |
| Size: 1010mm*460mm*35mm |
|
30A PWM Solar Charge Controller
| Battery voltage: 12V/24V |
Charging mode: PWM |
| Max Charge current: 30A |
Discharge current: 30A |
| Max.PV Open-Circuit Voltage: <50V |
USB Output: 5V/2A |
| Working Temperature: -20℃~60℃ |
Weight: 150g |
| Size: 138*82*30mm |
|
600W 12V Off Grid Inverter
| Rated Output Power: 600W |
Surge Output Power: 1000W |
| Rated Output Voltage: 120Vac ± 1% |
Output Freq.: 60Hz ± 0.2Hz |
| Waveform: Pure Sine Wave |
Total Harmonic Distortion: < 3% |
| Input PV Voltage Range: 10V-15V |
Efficiency: > 85% |
| No Load Current Draw: 0.85A |
Low Battery Alarm: 10.7V |
| Low Battery Shut-Down: 10V |
Dimension (L x W x H): 12.0*6.77*2.95 inch |
| Weight: 2.5kg (5.5 lbs) |
|
50Ah LiFePO4 Lithium Battery
| Battery Capacity: 50Ah |
Battery Power: 640Wh |
| Battery Voltage: 12.8V |
Maximum Charge/ Discharge Current: 50A/50A |
| Charge Temperature Range: 0-55℃ |
Disharge Temperature Range: ﹣20－55℃ |
| Maximum Charge Voltage: 14.5V |
Discharge Cut-Off Voltage: 10V |
| Screw size: M6 |
Battery Size: 223*135*185mm（8.8*5.3*7.3inch） |
| Battery Weight: 4.82kg（10.62lb） |
|
16.4 feet 12AWG Cables
| Cable Type: Connecting Solar Panels to Charge Controller |
Rating Voltage: 600/1000V |
| Length: 5 meters（16 ft） |
Conductor: Tinned copper wire |
| AWG: 11 |
Normal Cross Sectional Area of the Conductor (mm2): 4 |
| Waterproof: IP 65 Protection |
Temperature: -40°F to +185°F |
| Connector: MC4 |
Weight: 0.742KG |
Z Mounting Brackets
| 4 pieces of Z shape solar panel brackets |
8 pieces of stainless steel nuts and cap bolts |
Y Branch Cable MC4 Connectors
| Compatible with MC4 solar connector. |
Easy installation for 2 solar panels connected in parallel. |
